| C02-03

C02-03
TYPE:
CCTV camera
hits:
753
MINIMUM ORDER:
100 PCS
PACKAGE:
PCS
PAYMENT TERMS:
T/T
DELIVERY:
5 DAYS
QUOTATION:

Remarks:
CCTV camera---C02-03 Dome camera



图象传感器\Image Sensor    1/3〞SONY SUPER HAD  CCD

有效像素\Effective Pixels    PAL:752(H)×582(V)    NTSC: 768(H)×494(V)

感光面积\Sensing Area    4.9×3.7mm

信号系统\Signal System    PAL/NTSC

水平清晰度\Horizontal Resolution    480TV lines

快门速度\Shutter Speed     1/50(1/60)—1/100,000sec

白平衡\White Balance    Auto white balance

信噪比\S/N Ratio    More than 48db(AGC OFF)

最低照度\Minimum Illumination     0.8Lux /F1.2

视频输出\Video Output    1.0Vp-p,75Ω

电源供给\Power Requirement    DC12V

功能消耗\Power Consumption    150mA

工作温度\Operation Temperature    -10℃~+50℃ RH95%Max

视频接口\Video Out    BNC

尺寸\Dimensions    Φ100×65mm

净重/毛重\NW/GW    240g/310g





Shenzhen Baifuda Electronic is one of the leading manufacturer of the CCTV system,CCTV surveillance cameras and the CCTV accessories in China, our products such as----- CCTV CCD camera, CMOS camer, Dome Camera, Car Rear View Camera, Wireless CMOS Camera, Color Day & Night Waterproof Camera, DVR Card,and the Mounting bracket, PTZ control, video square ,  Video distributor. Speed Dome housing extension cable(Video connector + DC power connector), passive Balun-----UTP transmit,VGA cable with end DB25 connector to 16 video BNC plug, BNC connector, RG59 connector,RG59 cable,RCA connector, power supply,etc.
